Integrated Data: Your Voice Just Got A Lot Stronger
The MOTOTRBO XPR 5000e Series is a family of DMR standard digital radios that delivers operations-critical voice and data communications. Bluetooth® audio lets you talk without wires, integrated Wi-Fi® enables remote software updates, and indoor and outdoor location-tracking capabilities give you total visibility of your resources. With support for trunking as well as legacy analog technology, you can keep your organization connected as it grows.
Safeguard your staff with responsive push-to-talk technology. The quick access buttons on XPR 5000e Series radios can summon help with one touch, using Transmit Interrupt to clear a channel when necessary. A range of safe driving accessories allow your workers to communicate hands-free, and Text-to-Speech technology helps your drivers keep their eyes on the road.
Text messaging and Work Order Ticketing simplify complex communications, and data capabilities support advanced applications. Featuring a high power audio amplifier, these radios deliver loud, clear speech, with background noise cancellation for better intelligibility. XPR 5000e Series radios are also ideal as a dispatch solution, with desktop microphones and a rugged, durable design for everyday use.
Next-Generation XPR 5000e Series:
- Integrated Wi-Fi®, Ideal for Downloading New Software Remotely
- Integrated Bluetooth® 4.0, with Indoor Location-Tracking Capability
- Louder, Virtually Distortion-Free Audio for Super-Clear Communication
- Improved Expandability
- Innovative New Accessories
Motorola XPR 5550e Features
- Large, Full-color Display:
Enhanced 4-line display features a flexible menu-driven interface. Icons and large easy-to-use navigation buttons ease message reading and menu navigation.
- Bluetooth Data:
Share real-time information by connecting radios to Bluetooth-enabled data devices.
- Best-in-class Audio:
Loud front-facing speaker and Intelligent Audio feature automatically adjusts the radio volume according to the environment’s noise level.
- Day/night Display Mode:
Day mode displays improved resolution for easier viewing even in broad daylight, while night mode makes the screen easier to read in dark environments.
- Integrated GPS:
Locate mobile work teams using integrated GPS.
- Productivity-enhancing Data Applications:
Features the industry’s largest application developer program to enable a wide variety of customized applications including: location tracking, work order ticket management, Bluetooth data, email gateways, dispatch, telephony and man-down.
- Text Messaging:
Send update messages to team members when radio communications need to be delivered without interrupting workers or guests.
- Embedded Bluetooth Audio:
Enables connectivity with wireless accessories including Motorola’s unique Operations Critical Wireless earpieces designed for rugged and reliable communications.
- Emergency Button:
Orange P4 button can be optionally programmed to send an alert to a supervisor or dispatcher during an emergency situation.
- Transmit Interrupt:
Enables a user to interrupt another radio conversation to deliver critical communication exactly when and where it’s needed.
- Basic or Enhanced Privacy:
Built-in scrambling for increased security.
Motorola XPR 5550e Models
Motorola XPR 5550e
AAM28JQN9WA1AN 136-174 MHz, 25-45 Watts, 1000 Channels
AAM28QPN9WA1AN 403-470 MHz, 25-45 Watts, 1000 Channels
AAM28TRN9WA1AN 450-512 MHz, 1-40 Watts, 1000 Channels
Wi-Fi Enable Models
Motorola XPR 5550e
AAM28JNN9RA1AN 136-174 MHz, 1-25Watts, 1000 Channels
AAM28JQN9RA1AN 136-174 MHz, 25-45 Watts, 1000 Channels
AAM28QNN9RA1AN 403-470 MHz, 1-25Watts, 1000 Channels
AAM28QPN9RA1AN 403-470 MHz, 25-45 Watts, 1000 Channels
AAM28TRN9RA1AN 450-512 MHz, 1-40 Watts, 1000 Channels
Motorola XPR 5550e Series Accessories
MOTOTRBO radios are already best in class, but to help you work at your best, you need enhancements targeted to your specific workplace. Motorola has developed a line of accessories with unique features designed to optimize the performance of your radio in your work environment, unleashing the full power of the industry’s most advanced digital radio platform. As you walk from the production line, across hotel grounds, or to the store stockroom, you can work more easily and efficiently wearing a comfortable, convenient accessory. Combine Motorola’s best-in-class radios with accessories to achieve even greater productivity and cost-savings.
Together, you’ll rethink what’s an accessory – and what’s a necessity.
That’s why it’s important to use Motorola tested and certified accessories with your MOTOTRBO radios. They’re the only ones designed, built and tested with your radio to optimize its performance.
Motorola XPR 5550e Featured Accessory
Handheld Control Head for the XPR 5550e
This handheld control head for the XPR 5000e Series radios allows for total installation flexibility, in-vehicle mobility and total control of your mobile radio. The radio unit can be installed wherever it is most convenient: behind the seat, under the dash or in the trunk. The control head can then be mounted close to the user on a standard hang-up clip. The standard coiled cord is 5.9 ft. long and will stretch to 9.8 ft. (An optional extension cable adds 16.4 ft.) The control head allows users to move around within the vehicle and still stay connected. Ambulance attendants, bus drivers and delivery drivers can take the control head into the rear of the vehicle rather than being limited to the driver’s seat. With a full keypad, color screen, and channel and volume controls, the control head offers the full feature-set of a portable radio. Contact lists, text messages, radio settings, work order tickets and notifications are all accessible from wherever you are in the vehicl
Motorola Team Communications For High-Performing Organizations
How do you make communicating as easy as if your team was standing next to each other?
Teams are more dispersed than ever. The variety of users and user equipment in the workplace continues to multiply. Businesses want a way to make communication easier and faster, while leveraging the resources they already have in place. Whether you’re in the office, on site, or at a conference hundreds of miles away, with Motorola’s Team Communications solution your team is always just a “push” away.
